2013 hot sale panel pc with Intel atom D2550 CPU processor (PPC-104C) PPC-104C manufacturer from China ShenZhen LingJiang Computer Technology CO.,LTD

2013 hot sale panel pc with Intel atom D2550 CPU processor (PPC-104C)

Price:	500.0~648.0 USD
Payment Terms:	T/T,WU;Paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: PPC-104C

Production Capacity: 5000 sets per month

Delivery Date: one to two days

Type: Others

Material: brushed aluminum

CPU: Intel ATOM D2550 1.86G

RAM: DDR3 2Gb MAX 8Gb

LAN: 2*RJ45 Intel RTL8111C 1000...

HDMI: 1xHDMI

Operating Temp: -25 ~ 70 Celsius degree

Means of Transport: Land,Air

Packing: normal packing or according...

Form Factor: AT/ATX

Brand Name: Lingjiang

Size: 336.4x263x56.1mm

Chipest: Intel Atom D2550+ NM10

HDD: SSD32G

COM: 4 6xCOM (optional)

VGA: 1xVGA

Storage Temp: -40 ~80 Celsius degree

1. with intel atom d2550 processor
2. support HDMI,3G/WIFI
3.2xLAN, 1xVGA,6xCOM,4xCOM

PPC-104C

Features

1.The Fanless industrial panel pc was made of brushed aluminum in beautiful shape, no cable is good at shockproof, and high performance at low power consumption, can be used in hard environments. It supports wireless 3G/WIFI.

2. With the shockproof, moisture-proof, waterproof and dustproof (meet the NEMA IP65 standard), high temperature resistant, multi-solt and easy to expand characteristics, so it is widely used in industrial control,vehicle control, environmental control ,Miliary control,Monitoring system,Network security,Digital signage,Date storge and other automation applications.

3.With 10.4 inch resistive touch screen, brightness and contrast can be adjusted, and also have standby energy saving mode.It with integrated industrial-grade low-power embedded motherboard , support Windows 7 (Pre-install), Windows XP, Win7 system ,CF,HDD,SDD, multiple I/O interfaces.

Main components :

Model	PPC-104C 285x215x46.8mm
screen size	AUO 10.4 inch
Display area	211.2 x 158.4mm
Density Changer	*800600 1024768 (optional)*
Contrast	700:1 Typ
Screen colors	262K/16.2M 6-bit / 6-bit + FRC
Display brightness	450cd/m2
Touch panel	AMT Touch panel of resistance
Chipest	Intel Atom D2550+ NM10
CPU	Intel ATOM D2550 1.86G
RAM	DDR3 2Gb MAX 8Gb
SSD	SSD32G
System	Windows 7 (Pre-install) Windows XP/ win7
LAN	*2RJ45 Intel RTL8111C 1000Mbps**
USB 2.0	4
COM(COM)	4 6xCOM (optional)
VGA	1
HDMI	1
LPT	1 (optional)
Microphone Input/output	1 (optional)
Wireless 3G/WIFI	1(optional)
Operating Humidity	5 ~ 85% (non-Condensing)
Operating Temp	-25 ~ 70 Celsius degree
Storage Temp	-40 ~80 Celsius degree
Color	Black
Power	110V-240V AC
Power adapter	12V/5A DC
Weight	3.65KG/set
